CPU Specifications :
- Total Cores : 6
- Total Threads : 12
- Max Turbo Frequency : 4.30 GHz
- Intel® Turbo Boost Technology 2.0 Frequency‡ : 4.30 GHz
- Processor Base Frequency : 2.90 GHz
- Cache : 12 MB Intel® Smart Cache
- Bus Speed : 8 GT/s
- TDP : 65 W
Memory Specifications :
- Max Memory Size (dependent on memory type) : 128 GB
- Memory Types : DDR4-2666
- Max # of Memory Channels : 2
- Max Memory Bandwidth : 41.6 GB/s
- ECC Memory Supported ‡ : No
GPU Specifications :
- GPU Name‡ : Intel® UHD Graphics 630
- Graphics Base Frequency : 350 MHz
- Graphics Max Dynamic Frequency : 1.10 GHz
- Graphics Video Max Memory : 64 GB
- 4K Support : Yes, at 60Hz
- Max Resolution (HDMI)‡ : 4096 x 2160@30Hz
- Max Resolution (DP)‡ : 4096 x 2304@60Hz
- Max Resolution (eDP – Integrated Flat Panel)‡ : 4096 x 2304@60Hz
- DirectX* Support : 12
- OpenGL* Support : 4.5
- Intel® Quick Sync Video : Yes
- Intel® InTru™ 3D Technology : Yes
- Intel® Clear Video HD Technology : Yes
- Intel® Clear Video Technology : Yes
- # of Displays Supported ‡ : 3
- Device ID : 0x9BC8 / 0x9BC5
Expansion Options :
- Scalability : 1S Only
- PCI Express Revision : 3.0
- PCI Express Configurations ‡ : Up to 1×16, 2×8, 1×8+2×4
- Max # of PCI Express Lanes : 16
Advanced Technologies :
- Intel® Optane™ Memory Supported ‡ : Yes
- Intel® Thermal Velocity Boost : No
- Intel® Turbo Boost Max Technology 3.0 ‡ : No
- Intel® Turbo Boost Technology ‡ : 2.0
- Intel® Hyper-Threading Technology ‡ : Yes
- Intel® Transactional Synchronization Extensions : No
- Intel® 64 ‡ : Yes
- Instruction Set : 64-bit
- Instruction Set Extensions : Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
- Idle States : Yes
- Enhanced Intel SpeedStep® Technology : Yes
- Thermal Monitoring Technologies : Yes
- Intel® Identity Protection Technology ‡ : Yes
Security & Reliability :
- Intel® AES New Instructions : Yes
- Secure Key : Yes
- Intel® Software Guard Extensions (Intel® SGX) : Yes with Intel® ME
- Intel® OS Guard : Yes
- Intel® Trusted Execution Technology ‡ : No
- Execute Disable Bit ‡ : Yes
- Intel® Boot Guard : Yes
- Intel® Stable IT Platform Program (SIPP) : No
- Intel® Virtualization Technology (VT-x) ‡ : Yes
- Intel® Virtualization Technology for Directed I/O (VT-d) ‡ : Yes
- Intel® VT-x with Extended Page Tables (EPT) ‡ : Yes
** For any Missing Information please Refer to Intel Technologies Official Site.
